Pullmaster PL8 - Parts Reference - Brake Group

PAGE 22
700 1 22136 BRAKE HOUSING
703 1 25331 PLASTIC CAPLUG 3/4 NPT THR'D
707 1 25192 O-RING -174 8-3/4" ID 3/32" CS
710 1 20714 BACKUP WASHER FOR 25278
711 1 25278 OIL SEAL
712 1 21377 BRAKE SPACER
714 5 21252 DIVIDER PLATE
715 4 25194 FRICTION PLATE
717 2 25729 SUPPORT WASHER ANDERTON #R.28/40/2.0
720 1 20442 BRAKE HUB
722 1 21193 SPRAG CLUTCH ALIGNER
723 1 25187 SPRAG CLUTCH
724 1 21193 SPRAG CLUTCH ALIGNER
726 1 22672 SPRAG CLUTCH SPACER
727 1 25122 CIRCLIP ROTOR CLIP C-100
730 1 20448 MOTOR DRIVE SHAFT
731 1 25003 CIRCLIP ROTOR CLIP SH-75
733 1 25312 NEEDLE BEARING INA #HK3012
750 1 20434 PISTON
751 1 25309 O-RING -370 -90 DURO 8-1/4"ID 3/16" CS
752 10 20028 BRAKE SPRING
753 1 25309 O-RING -370 -90 DURO 8-1/4" ID 3/16" CS
800 1 21973 MOTOR ADAPTOR
801 1 25310 O-RING -012 -90 DURO 3/8" ID 1/16" CS
802 1 * SHUTTLE
803 1 25370 PIPE PLUG 1/16 - 27 NPT
804 1 * ORIFICE PLUG
805 3 25040 PIPE PLUG 1/8 - 27 NPT
807 1 * *
809 1 * PLASTIC CAPLUG 1/8 NPT
821 12 25118 CAPSCREW - HEX HEAD 3/8 - 16NC X 1.25 GRADE 5
823 12 25037 LOCKWASHER 3/8"
861 1 25323 GEAR HOUSING (2" GEARS) COMM. #312 8220 327
865 4 25326 DOWEL PIN COMMERCIAL #391 2082 032
869 2 25315 SEAL - BODY COMMERCIAL #391 2884 050
870 1 21759 PORT END COVER SUB-ASSY WITH PLUGS
875 4 25322 BEARING - ROLLER COMMERCIAL #391 0381 906
877 2 25908 SEAL - RING COMMERCIAL #391 2585 024
881 1 25317 GEAR SET (2" GEARS) COMM. #312 2820 007
885 2 25320 THRUST PLATE COMMERCIAL #391 2185 059
887 1 25321 SEAL STRIP COMMERCIAL #391 2882 051
899 2 25031 PIPE PLUG 1/4 - 18 NPT
929 1 * *
950 1 * SUB-ASSY MOTOR WM31 (2" GEARS)
951 4 25324 CAPSCREW - HEX HEAD 5/8 X 5.25 GRADE 5
953 4 25325 WASHER COMMERCIAL #391 3784 028
955 2 25556 PLASTIC CAPLUG 1.312" - 12
970 2 ** TIE BAR
971 16 25214 CAPSCREW - HEX HEAD 7/16 - 14NC X 1.50 GRADE 5
973 16 25328 LOCKWASHER 7/16"
23131 MOTOR SEAL KIT, CONSISTS OF ITEMS:
869, 877, AND 887.
MOTOR SUB-ASSY, ITEM 950, CONSISTS OF ITEMS:
800, 802, 803, 804, 805, 807, 809, 861, 865, 869, 870,
875, 877, 881, 885, 887, 899, 929, 951, 953, AND 955.
* These parts vary according to brake code. Refer to APPENDIX C.
** These parts vary according to drum code. Refer to APPENDIX B.
ITEM NO.
QTY.
DESCRIPTION
271 REV.970407
PART NO.
Refer to PAGE 20 for winch seal kit and PAGE 26 for ASSEMBLY DRAWING.
PARTS REFERENCE - BRAKE GROUP
