Pullmaster PL8 - Installation Dimensions

PAGE 24
I1024-1-C
271 REV.051117
INSTALLATION DIMENSIONS
[16]
.63
M
S
R c/c
K
ø
A
ø
B
OPTIONAL EXTERNAL
BRAKE RELEASE
PORT 1/8-27 NPT
C
I
[34]
1.3
G
J
D
F
E
L
H c/c
MOTOR PORTS
SAE O RING BOSS
SEE MOTOR CHART
FOR SIZES
FILLER PORT 3/4 - 14 NPT
4 MOUNTING HOLES 21/32 DIA [16.6] USE
ø
5/8 BOLTS
GRADE 5 OR BETTER
3/4-14 NPT DRAIN PORT
COUNTER-CLOCKWISE
GAUGE PORTS
1/4-18 NPT
PRESSURIZE FOR COUNTER-CLOCKWISE ROTATION
PRESSURIZE FOR CLOCKWISE ROTATION
[81]
3.2
FILLER PORT 1/2 - 14 NPT
CIRCULATION PORT 3/8NPT
(EXTERNAL CIRCULATION
MODELS ONLY)
Standard cable anchor is suitable for 3/8 - 9/16 inch diameter rope. FOR SAFETY: A minimum of 5 wraps of wire rope
must be maintained at all times.
