4
GM TRUCK SUPPORT BRACKET KIT #2616
This bracket kit fastens under the GM truck bed to the frame where the SuperLite’s rearward rail sits.This helps support
the hitch and prevents wear to the truck bed.The bracket kit is a no-drill install that clamps around the truck frame on both
sides.
REQUIRED WHEN USING THE #2600 SUPERLITE IN GM TRUCKS FROM YEARS 2010 - PRESENT
U-BOLT
GM TRUCK BED CUTAWAY VIEW
(DRIVER’S SIDE)
U-BOLT
BRACKET
Note: The brackets are identical and can be used for either side.
1. Place U-bolt around the truck frame at the point between the OE
and slide on brackets inside truck frame. If OE bracket is present, your truck is equipted with the OE prep package.
For this you will need the PullRite OE Puck Plug kit #2620
REVERSE VIEW
FRAME
REARWARD
BED SAVER RAIL
C
B
A
OVERLOAD
OE BRACKET
REAR BUMPER
OVERLOAD
OE BRACKET
(DRIVER SIDE)
#2616
KIT
D
