9
GOOSENECK RECEIVER INSTALLATION
The Gooseneck Receiver is the box that fastens to the original equipment (prep kit) gooseneck ball or aftermarket
1. Place Gooseneck Receiver over the ball in the truck bed as shown below. Connect with provided clevis pins
through the (2) holes in the bottom of the Gooseneck Receiver. Then fasten hairpin clips through clevis pins on both
sides.
ensure the hitch is placed in the correct position.
GOOSENECK RECEIVER
ABOVE VIEW
FORWARD REARWARD
RECEIVER
TO TAILGATE
BOLT
VIEW OF THE
RECEIVER
To Next Page
