7
HEIGHT ADJUSTMENT
The #2600 SuperLite is height adjustable and can be set at three positions. Refer to the illustration below and the “#2600
remove the bolts - just back out about two complete turns or until the coupler is loose in the base.
2. Remove the bent hitch pin and clip and adjust to the desired height.
3. Re-pin and clip.
Over-tightening these set
screws could cause damage to the base. Always torque properly.
Heights shown here
are installed heights. To
obtain the correct height
needed for towing, choose
the corresponding hole in
the coupler Tube.
The installed heights
listed here are measured
from the base of the hitch
to the top of the King Pin
Adapter (bottom of your
trailer’s pin box skidplate)
once properly installed.
NOTE: Two of the three
set screws are located
behind the PullRite
logo plate
