5| Assembly instructions
exploded view
2 x 4 x 8 x
M8 x 85 mm bolt, nut,
washer
M8 x 65 mm bolt, nut,
washer
3.3.
1.1.
2.2.
1.1. 3.3.2.2.
10 x 70 mm hexagon
screw, plasc dowel
