PUL
OON Tec
hnology
Inc.
LCDM-1000
25
-
Is CHK SENSOR 1& 2 nor
m
al
?
-
Is the
assem
b
ling condition of GUIDE CASH FEED 1&
GUIDE
CASH FEED 3 ASS’Y
nor
mal ?
-
Is i
dle roller rotati
o
n in the GUIDE CASH FEED 2 ASS
’Y
normal?
-
Is fi
xing screw in GUIDE CASH
FEED 1 / 2 / 3 ASS’Y
normal?
Check
Point
JAM at CHK Sensor
Meaning
-
Tr
y aga
i
n after checking above s
i
tuation.
-
In case
of Jam
, Tu
rn a knob shown be
l
ow
Action
33H
CODE
T
ABLE 2
25
