PULOON Technology Inc.
LCDM-1000
21
2. H/W Constitution
2-1. Layout of MAIN BOARD
24V 5V
Conversion
Circuit
BLDC MOTOR
Solenoid,Clutch
CPU,ROM,RAM
RS232
Communication
Circuit
RVDT
Circuit
EEPROM
DIP SWITCH
SENSOR Circuit
