PULOON Technology Inc.
LCDM-1000
20
- Segment Name
For reduction speed of ONEWAY ROLLER PULLEY REVERSE
(MXL42,￠8)
P7
For MOTOR running & Speed reductionBELT TIMING 108XL
(W=6.4)
T1
For transporting torque to PULLEY
( driving belt )
BELT TIMING 140XL
(W=6.4)
T2
For transporting torque to PULLEY
( driving belt )
BELT TIMING 108XL
(W=6.4)
T3
PULLEY for FEED ROLLER workingPULLEY FEED
(XL20, ￠8)
P5
For reduction speed of ONEWAY ROLLER PULLEY DRV MXL17P6
PULLEY for transporting ROLLERPULLEY FEED
(XL15,￠8)
P4
PULLEY MOTORPULLEY MOTOR
(XL16, ￠6)
P1
PULLEY for reduction of speedPULLEY CASH FEED 1 P2
PULLEY for transporting ROLLERPULLEY CASH FEED 2P3
For ONEWAY ROLLER running & Speed
Reduction
BELT TIMING 56MXL
(W=3.2)
T4
GEAR for transporting POWERGEAR DFDM DRIVE
(Z:27, M:1)
G2
GEAR for transporting ROLLER GEAR FEED
(Z:27, M:1)
G1
FunctionNameNO
(3) MOTOR
- MAKER : Fuji Micro
- TYPE : Brushless DC Motor
CW/
CCW
3500rpm
±200rpm
2400mA±
200mA
1kgf-cm4800rpm
±250rpm
180mA±1
00mA
DC 24VFB-806
SpeedCurrentTorqueSpeedCurrent
Rot
LoadNo Load
VoltageTYPE
