- Checking each sensor(Please refer to Self Diagnostic Method )Check Point
Damage to SENSOR Detail
- Replace damaged SENSORManagement
3ECODE
(8) EXIT SENSOR (7) EJT SENSOR
Note Path
(Delivery)
(16)WHEEL SENSOR
(5)(6) DIV SENSOR 1/2
(11)REJECT
TRAY S/W
(14) CASH BOX
SENSOR 0
(9) NEAREND
SENSOR 0
(1)(2)CHK
SENSOR 1/2
(12) RVDT
SENSOR 0
(13)RVDT
SENSOR 1
(10) NEAREND
SENSOR 1
(15) CASH BOX
SENSOR 1
(3)(4)CHK
SENSOR 3/4
