Pulsar Axion 2 LRF User Manual

Single Measurement Mode
1.
Press the ON/OFF (6) button briefly to power the device on.
2.
Activate the rangefinder by pressing the LRF (12) button briefly. A red
mark appears on the display.
3.
Place the rangefinder’s reticle on the target. Press the LRF (12) button
briefly to measure the distance to the object once.
4.
The measurement results are displayed in the upper right corner.
5.
The rangefinder shuts down after 3 seconds of inactivity.
Scan Mode
1.
Press the ON/OFF (6) button briefly to power the device on.
2.
Activate the rangefinder by pressing the LRF (12) button briefly. A red
mark appears on the display.
3.
Activate the scan mode by long pressing the LRF (12) button to
continuously measure the distance to objects.
4.
The measurement results are displayed in the upper right corner.
5.
Deactivate the rangefinder by long pressing the LRF (12).
Notes:
Additional rangefinder settings are available in the Rangefindersection

Pulsar Axion 2 LRF Specifications

General

Frame Rate	50 Hz
Laser Rangefinder	Yes
Wavelength of Laser Rangefinder	905 nm
Display Type	AMOLED
Photo/Video Recording	Yes
Built-in Memory	16 GB
Wi-Fi	Yes
Stream Vision 2	Yes
Waterproof Rating	IPX7
Range of Laser Rangefinder	up to 1000 m
Display Resolution	1024x768 px
Power Supply	Built-in battery
External Power Supply	USB Type-C
Operating Temperature	-25°C to +50°C
