Pulsar Axion 2 LRF User Manual

Possible cause
Calibration is required.
Solution
Perform image calibration according to the Calibration Mode section
of the manual.
Black screen after calibration
Solution
If the image does not clear after calibration, you need to recalibrate.
Poor quality image. There is noise or ghost
images of previous scenes or objects
Possible cause
Manual calibration has been performed with the lens cover open.
Solution
Check theCalibration Mode, close the lens cover and calibrate the
device.
Image is too dark
Possible cause
Brightness or contrast level is too low.
Solution
Adjust the brightness or contrast level in the Quick Menu.
Colour bars appear on the display or the
image disappears

Pulsar Axion 2 LRF Specifications

General

Frame Rate	50 Hz
Laser Rangefinder	Yes
Wavelength of Laser Rangefinder	905 nm
Display Type	AMOLED
Photo/Video Recording	Yes
Built-in Memory	16 GB
Wi-Fi	Yes
Stream Vision 2	Yes
Waterproof Rating	IPX7
Range of Laser Rangefinder	up to 1000 m
Display Resolution	1024x768 px
Power Supply	Built-in battery
External Power Supply	USB Type-C
Operating Temperature	-25°C to +50°C
