N
PART NO. DESCRIPTION Q'TY REMARK
DJ170F-11100-HE CRANKCASE 1
GB276-89-6205 BEARING RADIAL BALL 6205 1
DJ168F-11014-A
OIL SEAL Φ 25×Φ 41.25×6
1
DJ168F-15100-A
SPEED REGULATING GEAR
1
DJ168F-15001-A
MOVING STAFF
1
DJ168F-15002-A
PLAIN WASHER
1
DJ168F-15003-A
PIN, LOCK
1
DJ168F-11004-A
DRAIN PLUG
2
DJ168F-11005-A
WASHER DRAIN PLUG
2
DJ168F-18200-C OIL SENSOR ASSEMBLY
1
GBT16674-B6-16 BOLT FLANGE M6*16 2
DJ168F-18300-A
OIL ALRAM
1
GBT16674-B6-12 BOLT FLANGE M6*12 1
DJ168F-11039-A
Q CLIP
1
DJ168F-11400-A
WELDING COMP. WIND SHROUD
1
GBT16674-B6-20 BOLT FLANGE M6*20 1
PG3500M ENGINE PARTS LISTING
This list is provided for reference purposes only.All repairs and part replacement should be performed by a
qualified technician. Some parts may not be available as single replacements.
25
