Pulsar PG5250B User Manual

11
ASSEMBLY
Fig 3
Fig 4
Handle Assembly (See fig 3)
• Place generator on a level surface.
• Install handle lock holder by inserting bolt and lock nut. (fig 3)
• Install handle Bracket to frame with 2 bolts and lock nuts as shown on illustration.
• Set handle in the bracket aligning the holes and insert handle bolt and lock nut.
Remove the crankcase dipstick to ensure you do not overfill the engine.
•
• Insert a funnel into the crankcase dipstick hold and carefully add 4-Cycle engine oil (SAE10W- 30) to empty reservoir
until oil reaches the outer edge of the oil fill hole (crankcase dipstick hole).
• Be sure to replace dipstick before attempting to start the engine.
• To check oil, set generator on a level surface, wipe dipstick clean, then reinsert dipstick without rethreading.
Adding / Checking Engine Oil (See fig 4)
1
1
2
3
2
3
10W30 OIL
You must add oil before first operating this generator. Always check oil level before each
operation.
DO NOT USE E15 OR E85 FUEL IN THIS UNIT. IT IS A VIOLATION OF FEDERAL LAW AND
WILL DAMAGE THE UNIT AND VOID YOUR WARRANTY.
CAUTION!

Pulsar PG5250B Specifications

General

Brand	Pulsar
Model	PG5250B
Category	Inverter
Language	English
