Pulsar PROTON FXQ30 - Device Operation and Setup; Mounting Attachment on Optical Sight

ENGLISH
Operation
Mounting attachment on optical sight
•
Remove the eyepiece cover (2).
•
Select the Ring Adapter (12) (sold separately) with the insert (11) of the
required diameter depending on the outer diameter of the lens of your
optical sight (10) (see Table). The designation 42 mm / 50 mm / 56 mm in the
name of the adapter means the lens diameter of the optical sight.
Selection table for optical sight inserts
Ring
Adapter
model
The internal diameter of the insert needs to match the outer
diameter of the objective lens housing of the daylight optical
device it is being installed on.
Insert internal diameter,
mm
Suitable for lens housing of daylight
optical devices with an outer
diameter of, mm
PSP Ring
Adapter 42
mm
45.5 45.5
46 46
46.5 46.5
47 46.7-47.6
48 47.7- 48.6
49 48.7-49.6
50 49.7-50.6
PSP Ring
Adapter 50
mm
51.6 51.6
53.4 53.4
55 54.7-55.6
56 55.7-56.6
57 56.7-57.6
58 57.7-58.6
59 58.7-59.6
PSP Ring
Adapter 56
mm
60 59.7-60.6
61 60.7-61.6
62 61.7-62.6
63 62.7-63.6
64 63.7-64.6
65 64.7-65.6
•
Screw together the Ring Adapter (12) and the attachment along the threads
of the mounting area (17) until it stops. Then untighten a little (no more than
one turn) so that the lever (16) is on the right side (see Figure).
•
Evenly tighten the screws (13) until the ball joint grips in the Ring Adapter (12).
•
Apply 2-3 strips of double-sided tape to the outer surface of the insert (11)
of your choice.
•
Push the insert (11) of your choice into the Ring Adapter (12) until it stops.
•
Move the lever (16) to the OPEN position.
•
Before installing the Ring Adapter (12) onto the optical sight, it is
recommended to degrease the lens body of the optical sight (10).
•
Mount the Ring Adapter (12) with the insert (11) onto the lens of the daylight
optical sight (10) as far as it will go.
5
