5
2
1
3
4
Product Overview
2. Fuel Tank Cap
4. Height Adjustment
Checking the Engine Oil Level
Service Interval:
Before each use.
1. Remove dipstick, wipe it clean, and fully re-insert it,
check to see if oil is needed by the oil mark that is left
on the dipstick. (Fig. 9)
Remove the dipstick and check the oil level (Fig. 9) If
the oil level is low on the dipstick, slowly pour oil into
the oil fill hole to raise the oil level to the full range on
the dipstick. Do not overfill. Max fill 1 oz (0.4 L),
type SAE 30 weight oil with an API service rating
of SF or higher.
Install the dipstick and tighten the screw threads.
Fig. 9
4
Fig.6
1. Air Filter
3. Oil Fill / Dipstick
5. Handle Loosening Knob
Operation
Filling the Fuel Tank
Gasoline is extremely flammable with explosive vapors.
A fire or explosion from gasoline can burn you or others.
To prevent a static charge from igniting the gasoline,
place the container and/or mower directly on the
ground before filling, not in a vehicle or on an object.
Fill the tank outdoors when the engine is cold; wipe
Do not handle gasoline while smoking or near open
flame or sparks.
Store gasoline in an approved fuel container, out of
the reach of children.
Fill the fuel tank with fresh unleaded regular gasoline
from a filling station. (Fig. 8)
Important: To reduce starting problems, add fuel
stabilizer to the fuel, mixing it with gasoline less than
30 days old. (Fig. 8)
up spills.
Attachments / Accessories
A selection of Pulsar approved attachments and
accessories are available for use with the machine to
enhance and expand its capabilities. Contact your
Authorized Service Center or Distributor.
Filling the Engine with Oil
Your mower engine does not come filled with oil. Use
SAE
30 engine oil
1. Remove the dipstick. (Fig. 7)
2. Slowly pour oil into the dipstick/fill hole until the oil level
Fig. 7
Fig. 8
WARNING
