Pure Humidifier EC-15 User Manual

TM
Introduction
Introduction
Capacity & Electrical Specifi cations
Dimensions & Layout
Humidifi er Layout
Installation & Location
Wall Mounting Detail
Dispersion Methods
Injection Tube & Flexible Hose Kit Installation
Steam Supply Piping Examples
Piping
Blower Pack
Pre-Startup Checklist
Non-INTAC
®
PLC Startup Procedure
INTAC
®
PLC Startup Procedure
Maintenance & Cleaning Instructions
Cover Gasket Replacement Instructions
Troubleshooting
Tool Requirements & Torque List
Maintenance Notes
Exploded Parts Drawing
Parts List
1
2
3
4
5
6
7
8
9
10
11
13
14
15
16
17
18
19
20
21
22
To the user of PURE Humidifi er Co.’s Electric Humidifi ers
We at PURE Humidifi er Co. thank you for choosing one of our
quality products. PURE Humidifi er Co. Electric Series Humidifi ers
are models of simplicity to install, operate, and maintain. However,
they must be maintained to provide maximum operating
effi ciency.
PLEASE READ AND FOLLOW ALL INSTRUCTIONS
CAREFULLY. PROPER OPERATION AND HUMIDITY CONTROL
IS POSSIBLE ONLY WITH PROPER INSTALLATION AND
MAINTENANCE.
The EC Series Humidifi er utilizes a Tri-Probe Sensor conductive-
type water control system, which is designed for use with standard
(hard or soft) tap water. Use of deionized, demineralized, or reverse
osmosis water will cause a failure of the water level control system
and void the warranty.
High chloride content in feed water can cause chloride stress
cracking and chloride pitting in stainless components. Chloride
stress corrosion cracking (CSCC) and chloride pitting of stainless
steel components is not covered by warranty. Do not use
hydrochloric acid descalers or bleach to clean the tank. We off er an
easy-to-use, non-toxic descaling solution to help keep your units
clean and operating with maximum effi ciency. Please contact your
local PURE Humidifi er representative for more information about
our PURE Clean descaling solution.
PURE Humidifi er Co.’s ECDDR Series should be installed on
applications that require deionized, demineralized, or reverse
osmosis water.
To ensure proper installation of this product, it must be installed
by qualifi ed HVAC and electrical contractors, and must be in
compliance with local, state, federal, and governing codes. If
installed improperly this product may cause damage to property,
severe personal injury, or death as a result of electric shock, burns,
and/or fi re.
Do not adjust any components inside humidifi er control panel
without consulting the factory.
Installation of humidifi er in high humidity or salt water atmospheres
will cause accelerated corrosion, resulting in a reduction of the
normal lifespan of the unit.
For indoor use only.
Table of Contents
The PURE Humidifi er Co. Warranty
PURE Humidifi er Co. guarantees its products to be free from
defects in material and workmanship for a period of two years from
the date of shipment; provided the product is properly installed,
serviced, and put into the service for which it was intended.
PURE Humidifi er Co. is obligated under the terms of this warranty
to the repair or replacement of the defective part(s), excluding any
labor charges, or to refund the purchase price at our option. PURE
Humidifi er Co. assumes no obligation for incidental or consequential
damages. The above provisions are in lieu of all other guarantees,
obligations, liabilities or warranties, expressed or implied.
1

Pure Humidifier EC-15 Specifications

General

Brand	Pure Humidifier
Model	EC-15
Category	Humidifier
Language	English
