Pure Humidifier EC-15 User Manual

TM
Capacity, Weights &
Electrical Specifi cations
* EC-5 at 120/1 requires 3 heating elements.
† The above capacities are based on 100% effi ciency. Actual humidifi er capacity may vary due to the heat loss from the humidifi er
reservoir. The ambient air temperature, air velocity, and injection tube system will aff ect the rate of heat loss from the humidifi er reservoir.
Capacity & Weights
EC Series
Electrical Specifi cation
EC Series
Standard
Water Unit
Model No.
Steam Output Capacity † Humidifer Weight
lbs/hr kg/hr
Empty Full
lbs kg lbs kg
EC-5 15.0 6.8 139.0 63.1 223.0 101.2
EC-10 30.0 13.6 140.0 63.5 224.0 101.6
EC-15 45.0 20.4 141.0 64.0 225.0 102.1
EC-20 60.0 27.2 142.0 64.4 226.0 102.5
EC-25 75.0 34.0 143.0 64.9 227.0 103.0
EC-35 102.0 46.3 146.0 66.2 230.0 104.3
Standard
Water Unit
Model No.
KW
Single Phase Amperage Three Phase Amperage
CONTROL
CIRCUIT
VOLTAGE
No. of
Heaters
120V 208V 240V 480V 600V
No. of
Heaters
208V 240V 480V 600V
EC-5 5 Single 41.7* 24.0 20.8 10.4 8.3 Triple 13.9 12.0 6.0 4.8 24 vac
EC-10 10 Double 41.7 20.8 16.7 Triple 27.8 24.1 12.0 9.6 24 vac
EC-15 15 Triple 31.3 25.0 Triple 41.7 36.1 18.1 14.4 24 vac
EC-20 20 Triple 41.7 33.3 Triple 24.1 19.2 24 vac
EC-25 25 Triple 41.7 Triple 30.1 24.1 24 vac
EC-35 34 Triple Triple 40.9 32.7 24 vac
2

Pure Humidifier EC-15 Specifications

General

Brand	Pure Humidifier
Model	EC-15
Category	Humidifier
Language	English
