6
300
Room Prop Band
25% RH 301
Room Hysteresis
3% RH 302
Room Integral
5.00 Minutes per repeat 303
Cycle Time
1.0 Seconds 305
Duct Derivative
0.00 Minutes 309
PRESS TO
MOVE UP OR
DOWN THRU
THE HOME
DISPLAY
Note:
This is a complete listing of all
the displays and menu prompts.
Not all displays and menu
prompts will appear on your
controller as they are
dependent on your configuration
number. Prompts shown are
examples only and may not
represent your control settings.
MENU 300
PRESS AND HOLD FOR
3 SECONDS UNTIL MENU
APPEARS
MENU 300 - PID
(PROPORTIONAL,
INTEGRAL & DERIVATIVE)
Duct Prop Band
25% RH 306
Duct Hysteresis
3% RH 307
Duct Integral
0.00 Minutes per repeat 308
ENTER
Room Derivative
0.00 Minutes 304
RH Input Filter
1 Seconds 310
To Next Page
