PURE Juicer - Page 17

17
1 Grid Tray
2 Grid
3 Feed Tube
4 Pusher
5 Feed Pan
6 Chute
7 Cutter
8 Lock Tab
9 Motor Shaft & Flats
10 O-Ring
1 1 Feed Tube Mounting Hub
12 Top Cover
13 Juice Tray
14 Top
15 Center Post
16 Press Cover
17 Grab Tab
18 Front Cover
19 Base
20 Bumper
2 1 Slot
22 Spout
23 Press Chamber
24 Logo Badge
25 Rubber Foot
26 Press Plate
27 Valve Handle
28 Back Cover
29 Guide Rail
30 Anvil
3 1 ID Badge
32 Switch Bezel
33 Switch
34 Receptacle
35 Belt Cover
33
34
28 29 30 31
32
35
