MOTOR INFORMATION
3 2
1
60
IMPORTANT
NOTE ON 230
ELECTRICAL
SUPPLY
CONFIGURING THE MOTOR TO 230 VOLTS
The PURE Juicer has been designed to work anywhere in the world. The
motor is dual voltage and can be wired at the flip of a switch to run on
115v or 230v current. All motors are wired 115V unless otherwise marked.
Underneath the belt cover on the back of the Juicer body is a switch to
reconfigure the motor from 115V to 230V.
1. Loosen 3 screws on the right side of the belt cover.
Loosen and remove the three screws on the left side
of the belt cover. Remove cover.
2. Slide the switch to the 230V position.
3. Reattach the belt cover.
Exercise extreme caution; confirm
the motor is set up for 230V before
plugging it in. Never plug the 115V
motor into 230V or the motor will be
irreparably damaged.
