Purkeys INVERT - Call-Outs

6
CALL-OUTS
Positive DC
connection
from battery
Negative DC
connection
from battery
Inverter controller
with LED indication
of battery status
3 X 120 VAC outlet
Pure sinewave
inverter
Positive DC
connection
from battery
Negative DC
connection
from battery
Inverter controller
with LED indication
of battery status
3 X 120 VAC outlet
Pure sine wave
inverter
2 X USB
charging ports
Inverter controller
quick release clip
REV:
Drawn By:
Tolerance:
.X .25"
.XX .030"
.XXX .005"
Date:
#INVERT 1500 FOR SPEC SHEET
Scale:
1:6
Page 1of3
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
PURKEYS. ANY REPRODUCTION IN PART
OR AS A WHOLE WITHOUT THE WRITTEN
PERMISSION OF PURKEYS IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
Eng Appr:
Date:
All dimensions are in inches
unless otherwise specified.
Part #:
3rd Angle
Weight:
-
6/15/2018
DRAFT
*On the 2000 watt inverter, each AC outlet has a 15 amp circuit breaker/on-o switch.
If the circuit breaker trips, reset the circuit breaker/switch by turning the switch
o, then back on. e switches can also be used to individually switch the three AC
outlets on or o.
*
