PRODUCT NAME INSTALLATION GUIDE
INSTALLATION
Step 1: Select the best location and install the inverter in the cab or sleeper of
the tractor.
Step 2: Install the quick release clip
in a convenient location (i.e. the
interior wall of the tractor). It
can be installed in either of the
following ways:
• Use the provided velcro and
stick the clip to the selected
location.
• Use the provided athead
screws to mount the clip.
Step 3: Connect the cable to the REMOTE connection on the inverter, then to
the connection on the base of the controller.
*
* is ground stud is already connected internally to the battery ground stud, the
inverter housing, and the ground of the AC sockets; therefore, it does not need to
be connected in vehicle applications.
