PV Powered Grid-Tied - Appendix B - Dimensions; Figure B-1 Side and Front Views of PVP1100 W, PVP2000 W, PVP2500 W, PVP2800 W, PVP3000 W, and PVP3500 W Inverter Cabinet

27
Figure B-1 Side and Front Views of PVP1100W, PVP2000W, PVP2500W, PVP2800W,
PVP3000W, and PVP3500W Inverter Cabinet
15 5/8"
30 3/8"
LED STATUS INDICATORS
VFD DISPLAY
3"
1"
7 1/4"
10"
1 1/8"
1"
3/4", 1" K.O.
1/2", 3/4" K.O.
LEFT VIEW
FRONT VIEW
