PV Powered Grid-Tied - Figure B-3 Side and Front Views of the PVP4600 W, PVP4800 W, and PVP5200 W Inverter Cabinet

29
Schematics for PVP4600W, PVP4800W, and PVP5200W Inverter CabinetB.2
Figure B-3 Side and Front Views of the PVP4600W, PVP4800W,
and PVP5200W Inverter Cabinet
18 1/8"
35"
LED STATUS INDICATORS
VFD DISPLAY
7 5/8" 1"
3"
1 1/8"
1 1/8"
9"
3/4",1" K.O.
1/2", 3/4" K.O.
LEFT VIEW
FRONT VIEW
