INSTALLATION
Location:
• Install the unit on a flat, dry surface.
• Leave at least 50cm of space all around the unit.
Temporary method
1. Fix the end of the exhaust duct to the exhaust terminal of the unit.
2. Half-open the window and let the air outlet duct through.
The window slider kit has been designed to fit most standard vertical and horizontal windows. It is adjustable.
Permanent method
1. Fix the end of the exhaust duct to the exhaust terminal of the unit.
2. Cut hole (＞Φ155mm) into the wall.
3. Fit the supplied round exhaust on the air outlet duct.
Mounting in the wall
