CONNECT TO BLUETOOTH DEVICES
1. Press MODE button to choose Bluetooth mode, displays BLUETOOTH on the screen .
2. Set your Bluetooth device to "Discoverable." This will allow your device to discover the PDA7BU or BT.
3. Select the PDA7BU or BT Bluetooth name and wait for the device to pair.
4. The PDA7BU will emit a noise conrming that the devices have successfully paired and the screen will
display “BLUETOOTH CONNECTED”
5. Once paired you can play music from your Bluetooth device. You can also use the control buttons on the
unit to select the tracks from your Bluetooth device.
B. PLAY/PAUSE BUTTON: Each press of the PLAY/PAUSE BUTTON causes the operation to change from
play to pause or from pause to play in the USB/SD mode or BLUETOOTH mode.
Presses the PLAY/PAUSE BUTTON one time to auto scan all frequencies from 87.5MHz to 108MHz, the unit
will auto store the channel.
C. STOP BUTTON: Press this button to stop play in the USB/SD mode.
D. REPEAT/FOLDER BUTTON: This button allows you to set one of repeat mode with ALL, NORMAL,
SINGLE, RANDOM, FOLDER and BROWSE in the USB/SD mode.
ALL: All tracks in the USB or SD CARD will be repeated in order without interruption.
NORMAL: All tracks in the USB or SD CARD will be played in order without interruption, the unit will stop
working after playing the last track.
SINGLE: Repeat the track that was playing.
FOLDER: All tracks in the current folder will be repeated in order without interruption.
RANDOM: All tracks in the USB or SD CARD will be played at random.
BROWSE: All tacks in the USB ore SD CARD will be played 10 seconds in order without interruption.
Hold this button for 3 seconds into FOLDER mode, the word FOLDER will ash on the screen, press PREV or
NEXT BUTTON to search through the folder, press again or hold this button for 3 seconds will exit the
FOLDER mode, or the unit will auto exit the FOLDER mode after waiting for 5 seconds.
E. PREV BUTTON: Use this button to select previous track or folder, depending on these two dierent
modes as below.
* In TRACK mode: Use to select previous track.
* In FOLDER mode: Use to select previous folder.
F. NEXT BUTTON: Use this button to select next track or folder, depending on these two dierent modes as
below.
* In TRACK mode: Use to select next track.
* In FOLDER mode: Use to select next folder.
17. RCA SUBWOOFER OUTPUT: To connect with the extra active subwoofer power amplier.
18. AUDIO INPUT: Connect the audio output RCA jacks of DVD/CD, to these RCA jacks.
19. SURROUND AND CENTER OUTPUT: Connect with the surround and center speaker by connecting with
those spring-loaded speaker terminals.
20. MASTER OUTPUT: To use the combo screw-type banana plug speaker jacks to connect with the L/R
speaker.
21. BLUETOOTH ANTENNA: Please pull the antenna out when using Bluetooth input
22. FM ANTENNA CONNECTOR: Connect for FM antennas.
24. POWER SUPPLY: Connect to AC power socket.
23. POWER VOLTAGE SELECTOR: According to the current power voltage, push this switch to choose
110V or 220V.
