Pyle PDA7BU User Manual

www.PyleUSA.com
5
REMOTE CONTROL
1. Press this button to turn on the MP3
2. In FM mode, press this two buttons to select
previous or next channel.
3. Press these two buttons to select the previous
or next track in USB or SD or Bluetooth mode
4. Volume up or down
5. Press the numbers to select the tracks directly.
The unit takes 1-2 seconds to response in USB or SD mode.
6. Press this button to select the dierent repeat mode.
Pressing this button for more than 3 seconds will
enter into FOLDER searching
7. Press this button to select the playing mode, such as
USB/SD/FM/BLUETOOTH
8. EQ function, if the mp3 with EQ
9. Play and pause function for MP3
Main Features
• RackMount Amplier Receiver
• 2.1 Channel Audio Amp Design with Surround
and Center Speaker Outputs
• BluetoothWireless Audio Streaming Ability
• USB Flash & SDMemory Card Readers
• FM Radio with Digital LCD Display
• ID3 Tag Readout Displays Song Title
• Folder name displays
• Folder search
• Aux (3.5mm) Input Jack
• Connect & Stream Audio from External Devices
• Multi-Source RCA (L/R) Audio Input Connectors
• 1/4’’Microphone Inputs
• Spring-Loaded Speaker Terminals
• Combo Screw-Type Banana Plug Speaker Jacks
• RCA Subwoofer Output
• Front Panel Button Control Center
• Independent Input Source Selectable
• Bass,Treble, Balance, Source Volume Adjustable
• Includes Removable RackMount Brackets
Bluetooth Connectivity
• Built-in Wireless Music Streaming Receiver
• Compatible with All of Your Favorite Bluetooth
Devices (IPhone, Androids, Smartphones, iPad,
Tablets, etc.)
• Bluetooth Version: 2.1
• Bluetooth Network Name: “PDA7BU” or “BT”
• Wireless Range: 30’+ ft.
What’s in the Box
• Amplier Receiver
• Remote Control
• Detachable Hardware Rack Mounts
• FM antenna
• Manual
• Warranty card
Technical Specs
• Input current: 30mA
• Construction Material: Metal, Aluminum Alloy Panel
• Frequency response: 20-20KHz, +/-2dB
• S/N Ratio: >85dB
• T.H.D.: <1.0%
• Input sensitivity: 200mV (Max Output: 6000mV)
• Maximum USB Flash & SD Memory Card Support
Size: 32GB
• Digital Media File Support: MP3, WAV
• Battery Operated Remote Control, Requires 3V
• Lithium Battery
• Power Cable Length: 4.5’ ft.
• Power: 110/240V, Switchable
• Dimensions (L x W x H): 19.0’’ x 9.8’’ x 2.2’’

Pyle PDA7BU Specifications

General

Brand	Pyle
Model	PDA7BU
Category	Amplifier
Language	English
