15A
Front RCA Output(Left)
Front RCA Output(Right)
Rear RCA Output(Left)
Rear RCA Output(Right)
EXternal MIC
SWC
HANDS FREE PUSH-TO-TALK
PUSH-TO-TALK
• Allows you to access SIRI or GOOGLE voice via Wireless BT.
• Your phone must support SIRI or GOOGLE voice. Once connected to BT, your phone will ask for access
to your contact list.
• Now you are ready to use PUSH-TO-TALK. Press the PUSH-TO-TALK icon.
You are ready to talk. Call "(CONTACT NAME)" The system will call without
having to use your phone.
WIRING CONNECTIONS
CONTROL PANEL BUTTONS
ANT:RADIO ANTENNA JACK
F-L:Front RCA Output(Left)
F-R:Front RCA Output(Right)
R-L:Rear RCA Output(Left)
R-R:Rear RCA Output(Right)
Power/speaker Connector
FUSE 15A
PRECAUTION
+12V DC
NEGATIVE
EARTH
