Pyle PLSD131BT - Control Panel; Unit Keys Overview

-18-
UNIT KEYS
Control Panel
1. OPEN BUTTON
2.
3. MOD
4. BUTTON
5. TA/AF BUTTON
6. PAIR
7. MUTE BUTTON
8. BUTTON
9. REL BUTTON
SEL BUTTON and VOL KNOB
POWER/ E BUTTON
>>|/
/BAND BUTTON
>||/CH1-6
10. |<</ BUTTON
11. EJECT BUTTON
12. IR SENSOR WINDOW
13. USB PORT and COVER
14. AUX IN JACK
15. LCD SREEN
16. SD/MMC CARD SLOT
17. RESET BUTTON
18. MICROPHONE
Control Panel
Sliding Pl ate diagram af ter remo ving Co ntrol Panel
