Pyle PSBV250BT User Manual

7
Remote Control
1
Switch the unit between ON and
STANDBY mode.
2 SOURCE
Select the play function.
3 VOL+/VOL-
Increase/decrease the volume level.
4
H
/
G
In Bluetooth mode, skip to previous/next
audio file.
5
BF
In Bluetooth mode, start or pause
playback.
6 PAIR
Activate the pairing function in Bluetooth
mode and disconnect the existing paired
Bluetooth device.
7 MUTE
Mute or resume the sound.
8 EQ
Select a preset sound effect.
Preparations
Prepare the Remote Control
The provided Remote Control allows the unit to be operated from a distance.
t

Even if the Remote Control is operated within the effective range (6m), remote control
operation may be impossible if there are any obstacles between the unit and the remote
control.
t

If the Remote Control is operated near other products which generate infrared rays, or if
other remote control devices using infra-red rays are used near the unit, it may operate
incorrectly. Conversely, the other products may operate incorrectly.
First-time use:
The unit has a pre-installed lithium CR2025 battery. Remove the
protective tab to activate the remote control battery.
-
0
3
5
/
1
2
4

Pyle PSBV250BT Specifications

Power

power requirements	AC 120V 60Hz
power consumption	20 W
output power	20 W x 2

Audio Specifications

total harmonic distortion	1% (1kHz, 1W)
audio input sensitivity	700 mV
frequency response	40Hz - 20KHz

Weight and Dimensions

width	806 mm
height	62 mm
depth	60 mm
