Pyle PSBV250BT User Manual

4
Placement and Mounting
Placement
A If your TV is placed on a table, you can place the unit on the table directly in front of the TV
stand, centered with the TV screen.
B If your TV is attached to a wall, you can mount the unit on the wall directly below the TV
screen.
Option - A Option - B
Wall Mounting (if using option-B)
Note:
- Installation must be carried out by qualified personnel only. Incorrect assembly can result in
severe personal injury and property damage (if you intend to install this product yourself,
you must check for installations such as electrical wiring and plumbing that may be buried
inside the wall). It is the installer’s responsibility to verify that the wall will safely support the
total load of the unit and wall brackets.
- Additional tools (not included) are required for the installation.
- Do not overtighten screws.
- Keep this instruction manual for future reference.
- Use an electronic stud finder to check the wall type before drilling and mounting.

Pyle PSBV250BT Specifications

Power

power requirements	AC 120V 60Hz
power consumption	20 W
output power	20 W x 2

Audio Specifications

total harmonic distortion	1% (1kHz, 1W)
audio input sensitivity	700 mV
frequency response	40Hz - 20KHz

Weight and Dimensions

width	806 mm
height	62 mm
depth	60 mm
