a. Power cable

Power Cable

Length(M)

0.4

1

3

5

4AWG，

GT25-8

Terminals

Positive

WI0PRT121266

WI0PRT121267

WI0PRT121268

WI0PRT121269

(Orange)

Negative

WI0PRT121262

WI0PRT121263

WI0PRT121264

WI0PRT121265

(Black)

b. Internal Communication cable

Internal Communication

cable

Length(M)

0.4

1

3

5

CAT6，Black，

2*ALTW M12 Connector

WI0SRT121254

WI0SRT121255

WI0SRT121256

WI0SRT121257
