4) If require enable heater feature, insert the Dry contact heater terminal into
the I/O port of the Master Battery only.
Dry Contact
Heater
Terminal
After power on the system, insert into the I/O port on the
master battery, the heater feature will be enabled to
automatically function when necessary
Note:
1) After the battery module powered on, the pre-charge circuit of the battery
will last for 300mS to ensure current-limited charging to the capacitor of
external load/charger.
2) During capacity expansion or replacement, please shut down all the
batteries and ensure that the voltage of the battery is similar to each other
(voltage: <0.1Vdc OCV difference),or fully charge the system.
3) If determines to not use the modules for long term or disable the heater
feature to save power, remember to disconnect the heater terminal.
