7
Basic Parameters
Value
Nominal Voltage (V)
12.8
Nominal Capacity (Ah)
100
Dimension (mm)
325（L）*173.5（W）*226（H）
Weight (Kg)
12
±0.2
Discharge Voltage Range (Vdc)
10.8~14.4
Recommended Charge Voltage (Vdc)
14 ~ 14.4
Recommend Charge/Discharge Current (A)
50
Max. Continue Charge/Discharge Current (A)
100
Peak Discharge Current (A)
200@30sec
Communication
CAN
500Kbps,
RS485
default for console,
115200bps
Bluetooth
BLE5.0
Dry Contact
2 inputs,2 outputs
Maximum series-parallel configuration
4S4P
Maximum number of battery modules
supported(pcs)
16
Working Temperature
-40℃～60℃*
Environment Temperature
IP rating
IP67
Short circuit rating
500A
Humidity
5 ~ 95%(RH) No Condensation
Altitude(m)
<4000
Certification
IEC/ CE /FCC/ROHS/Telec
/UN38.3
Design life
10+yrs
Cycle Life
>4,500 25℃
Reference to standards
UL1973,IEC62619,FCC,CE ，
Bluetooth SIG, Telec,
* Charging is only available between 0 - 60℃
Between -40 - 60℃, discharge only available for heating film using.
