Pylontech FORCE H Series - Configuration; Quotation Item

Configuration
Quotation Item:
1. Battery Module(FH48074/FH9637M) – varying amount depends on application.
2. BMS(FC0500-40S/FC0500M-40S) – 1pcs per system, include external cables.
Item Amount
Min.
Voltage(Vdc)
Max.
Voltage(Vdc
）
Nominal
Capacity(kWh)
Usable
Capacity(kWh)
Rated
Power(kW)(1)
Peak Power
(kW, 15S)(1)
Min. Back-up
time(2)
Force - H1
3 130.5 162 10.7 9.6 5.3 5.8 1.8hrs
4 174 216 14.2 12.8 7.1 7.7 1.8hrs
5 217.5 270 17.8 16.0 8.9 9.6 1.8hrs
6 261 324 21.3 19.2 10.7 11.5 1.8hrs
7 304.5 378 24.9 22.4 12.4 13.4 1.8hrs
Force - H2
2 174 216 7.1 6.4 3.6 7.7 1.8hrs
3 261 324 10.7 9.6 5.3 11.5 1.8hrs
4 348 432 14.2 12.8 7.1 15.4 1.8hrs
(1)Rated/Peak Power is base on ideal operation temperature(10
- 40
℃
)
，
during charging the power will leveling decrease when reaching full capacity.
(2) Min. Back
-up time is base on rated power and related condition during beginning of life, in real application please consider the load.
