2) Cable connection: Ground cable connection:
1) Based on metal directly touch between the module’s surface
and rack’s surface. If using painted rack, the corresponding
place shall remove the painting.
2) Install a grounding cable to the grounding point of the
modules.
Figure 13: Battery rack
Figure 14: Battery grounding point
