1
1. Introduction
LV-Hub is the CAN/RS485 communication hub for multiple 48V battery groups in parallel connection.
Fit Description: US2000 / US3000 / Phantom-SA / US1800.
2. LV-Hub-A
No. Item Parameter
1 Operating voltage range 48 Vdc
2 Communication interface CAN/RS485
3 System Consumption 2W
4 Size 442*190*44mm
5 Protection degree IP20
6 Weight 3.0kg
7 Operation Life 15 years
8 Working temperature -20~60℃
9 Storage temperature -40~80℃
10 CAN (Max 25 groups) Baud rate: 500K; terminal resistance: 0/120Ω
11 RS485 (Max 5 groups) Baud rate:9600/115200
