Pylontech UP2500 User Manual

1 9UPSV050 1
11 /19
4. Installation
4.1 Package Items
Unpacking and check the Packing List
1) For battery module package:
Two power cables and one communication cable for each battery package:
t;J
P:0
Grounding cable:
1000 - -
ctnl ====n ========
Grounding cables use 1OAWG yellow-green cables.
UP2500 modules' ground i ng i s based on metal d i rectly touch between the modu l e's
surface and rack ' s surface. I f uses norma l rack, make sure the paint at the connection
place of rack i s removed or i nstal l a g round i ng cab l e to the roundi ng po i nt of t h e module
PO\'ll!R
001
OFf
• •
@
•
Grounding Point
