Pylontech UP2500 User Manual

7 /1
9
1 9UPSV0 5 0 1
2.2 Specifications
-
lj,(e1u1111 :-
-
,r :r L ,
Ill:i J ' .. tit I
Nominal Voltage (V)
25.6
Nominal Capacity (Wh)
2840
Usable Capacity (Wh)
2550
Dimension (mm)
442*420* 120
Weight (Kg)
26.5
Discharge Voltage (V)
23.2 - 28.5
Charge Voltage (V)
28.2 - 28.5
Recommend Charge/Discharge Current (A)
56
Max. Charge/Discharge Current (A)
85
Peak Charge/Discharge Current (A)
100 A@ l5sec
Communication
RS485
Configurat ion (max. in 1 battery group)
20pcs
Working Temperature
o c-55·c Charge
- 1o c-55°C' Discharge
Shelf Temperature
-2o c-6o c
Ingress Protection
IP20
Humidity
5% - 95%
Altitude
<2000m
Certification
IEC62619 I CE/ RoHS I UN38.3
Design life
10+ Years (25°C /77°F)
•
•
•
