SPECIFICATIONS
Power output
Min. RMS, both channels driven, from 40-20 kHz, with no more than 0.1% total harmonic distortion.
30 watts per channel into 6 ohms.
Load Impedance…………………..6 ohms
Total Harmonic Distortion………less than 0.05% at 1/2 rated RMS power output.
Frequency response (at 1 watt)…..20 to 20 kHz, + 1 dB, -2dB
Input sensitivity and impedance (at 1 kHz for rated power
output)
TUNER, TAPE PLAY………..250 mV/47 kohms
Output level (1 kHz)
TAPE REC……………………250 mV into 47kohms
Signal to noise ratio (short-circuit, A-network)
TUNER, TAPE PLAY….70 dB
Power requirements
Power voltage…….220V--230V--50Hz
For U.K………240V, 50Hz
For U.S.A & Canada…..110V, 60 Hz
Power consumption……watts VA Rated
Watts maximum
Dimensions………..420 x 135 x 230mm (W x H x D)
Weight………………6.2 Kg
Design and specifications for subject to changes without notice for improvements.
