5.13.2 Wired Devices?
View Inputs
This option views the status of all wired inputs: Open, Close, Tamper, and Fault.
Endstation Inputs
The status of the inputs will be shown. C = Closed. O = Open. F = Fault, T = Tamper. The
resistance reading can also be shown by pressing t for any of the above for statuses.
RIX Inputs: Choose the RIX ID from [0] to [3] to view the inputs status.
View PSUs?
This option allows diagnostics of the power supply information for the PSU on the control panel as
well as all the additional peripheral devices such as a RIX or ROX that have a PSU on board.
Endstation PSU
End station voltage readings are displayed = Voltage: 13.7V.
RIX PSUs
Choose the RIX ID from [0] to [3] to read the PSU voltage readings.
ROX PSU
Choose the ROX ID to read the PSU voltage readings.
Keypad Volts
Choose the Keypad ID from [0] to [3] to read the keypad voltage.
Reader Volts
Choose the Reader ID from [0] to [3] to read the reader voltage.
5.13.3 Communications
This function displays the information gathered from the communication device currently fitted.
GPRS Module:
GPRS Signal Strength: The range ‘0-31’ indicates the signal (31 = Excellent. <15 = Poor). ‘--.-- ‘
indicates no signal.
App or ARC Status messages: Displays the current connection status of the Pyronix Cloud.
Initialising – The panel is attempting to connect to the mobile network
No Network – There is no network available
Basic Network – The GSM network is available
Full Network – The panel is logged onto the GPRS network
Polling Cloud (App only) – The panel is polling the cloud
Polling ARC (ARC only) – The panel is polling the ARC
Last Polled Cloud: Displays the time period since the last successful poll to the Pyronix Cloud.
Last Polled ARC: Displays the time since the last successful poll to the ARC.
LAN Module:
IP Address: Displays the IP address of the LAN Module (if installed).
Subnet Mask: Displays the Subnet Mask of the LAN Module (if installed).
Gateway: Displays the IP address of the Gateway.
App or ARC Status messages: Displays the current connection status of the Pyronix cloud.
Initialising – The panel is attempting to connect to the network
No Network – There is no network available
Polling Cloud (App only) – The panel is polling the cloud
Polling ARC (ARC only) – The panel is polling the ARC
Last Polled Cloud: Displays the time period since the last successful poll to the Pyronix Cloud.
Last Polled ARC: Displays the time since the last successful poll to the ARC.
Wi-Fi Module
