3.1
DEVICE REPAIR AND RETURN
The detector is not designed to be repaired in
the field. If it is determined that the problem is
caused by an electronic defect, the device must
be returned to the factory for repair. The sensor
module is field replaceable in case of dirtiness,
damage, or failures incurred in the field.
Prior to returning devices, contact the nearest
local Det-Tronics office so that a Return
Material Authorization (RMA) number can be
assigned. A written statement describing the
malfunction must accompany the returned
device or component to assist and expedite
finding the root cause of the failure.
Pack the unit properly. Always use sufficient
packing material. Where applicable, use an
antistatic bag as protection from electrostatic
discharge.
NOTE
Det-Tronics reserves the right to apply a
service charge for repairing returned
product damaged as a result of improper
packaging.
Return all equipment transportation prepaid to
the factory in Minneapolis.
ORDERING INFORMATION
When ordering, please specify:
30-3013 Explosion Proof Smoke Detector
Refer to the 30-3013 Model Matrix for details.
For assistance in ordering a system to fit your
application, please contact:
Detector Electronics Corporation
6901 West 110th Street
Minneapolis, Minnesota 55438 USA
Operator: (952) 941-5665 or (800) 765-FIRE
Customer Service: (952) 946-6491
Fax: (952) 829-8750
Web site: www.det-tronics.com
E-mail: det-tronics@carrier.com
SPARE PARTS
30-3013 Replacement Sensor Module
104286-001
ACCESSORIES
Canned Smoke 000119-008
000119-046
Grease (silicone-free) 005003-001
Magnet
102740-002
Magnet with Extension Pole
007739-001
Stop Plug, 3/4" NPT, AL
101197-001
Stop Plug, M25, AL
101197-005
Q3013D-1 Duct Mount w/1 ft. tube 012894-001
Q3013D-1 Duct Mount w/3 ft. tube 012894-003
Q3013D-1 Duct Mount w/6 ft. tube 012894-006
Q3013D-1 Duct Mt. w/10 ft. tube 012894-010
30-3013 MODEL MATRIX
MODEL DESCRIPTION
30-3013 Explosion Proof Smoke Detector
TYPE MATERIAL
A Aluminum
TYPE PORT
1 1 Port
2 2 Port
3 3 Port
4 4 Port
TYPE THREAD
M Metric M25
N 3/4" NPT
TYPE OUTPUT
12 0-20 mA, Relay, Non-Latching
13 0-20 mA, Relay, Latching
TYPE APPROVAL
A FM/IECEx/CSA
