8 INSTALLATION AND OPERATION MANUAL FOR CIGS SOLAR MODULES Q-CELLS SE - EUROPE
5.1 MOUNTING VARIANTS
Please refer to the Q.CELLS clamp list regarding:
• approved mounting variants,
• approved clamps.
Only apply approved mounting variants and approved clamps for the installation.
The clamp list is available on www.q-cells.com.
With the point support, the mdule must not have contact with the subconstruction. The module
shall be supported by the clamp only. Please take into account that a module can bend up
to 15 mm under a snow load of 2400 Pa. The module glas must not have contact to under-
construction at any time.
With linear support, the modules lie along the lateral sides on the substructure. When using
this mounting variant, place a silicone-free rubber support plate between the substructure and
the clamps.
CAUTION! Incorrect orientation of the module may cause risk of re hazard!
The modules may be installed in landscape or portrait format.
Install the module in such a way that the junction box is positioned in the upper area of
the module and the wires hang downwards.
Ensure that the drainage openings of the frame are left open following installation to allow
water runoff. This prevents frost damage.
Install the modules with a minimum tilt angle of 3° and a maximum tilt angle of 75°.
Facade installations are not allowed.
For installations with a tilt angle < 20°, regularly check for dirt built up (soiling, bird drop-
pings, etc.). Rain should help to remove soiled areas, though regular cleaning is recom-
mended for all installations (see Chapter 7 “Cleaning and maintenance”).
Install the module in such a way that rainwater and snowmelt can run off freely to avoid
standing water or puddling.
The optimal tilt angle of the module depends on the respective latitude. We recommend
a photovoltaics simulation tool to ensure the optimal orientation.
MOUNTING VARIANTS
AND CLAMPS
SPECIFICATIONS FOR
POINT SUPPORT
SPECIFICATIONS FOR
LINEAR SUPPORT
MODULE ORIENTATION
AND TILT ANGLE
MODULE
