8786
Parameter QC804 QC808 QC8016
Control Mode Front panel, USB mouse, IR remote control,
Keyboard, Network
Compression Compression
Format
H.264 and MPEG-4 dual codec
Video Video In 4 channel input directly through POE block
4 additional
channels
through network
12 additional
channels
through network
Video Out
VGA x 1, BNC x 1, HDMI x1
VGA Resolution 1920×1080, 1280×1024, 1280×720, 1024×768
Record Resolution 1080P(1920×1080) / 720P(1280×720) / D1
(704×576/704×480)
Record Frame Rate D1:
30fps/camera
720p:
30fps/camera
1080p:
30fps/camera
D1:
30fps/camera
720p:
30fps/camera
1080p:
15fps/camera
D1:
30fps/camera
720p:
15fps/camera
1080p:
7fps/camera
Record Bit Rate Up to 32Mbps
Supported IP
Cameras
Dahua, Arecont Vision, AXIS, Canon, Dynacolor,
Panasonic, Samsung, Sanyo, Sony, Onvif
Audio Audio Input 1 channel, RCA(200-2800mV, 30KΩ)
Audio Output 1 channel, RCA(200-3000mV, 5KΩ)
Alarm Alarm Input 16 Channel
Alarm Output 3 Channel
Storage Record Mode Manual/Sensor/Schedule/Motion Detection/Camera
Loss/Camera Block/Alarm
Multi-Function Simultaneously Record, View Live or Recorded Video,
Playback, Back-up files, Monitor Remotely
Interface Network Interface RJ45 (LAN, Internet)
Communication
Interface
RS485, RS232
USB 2.0 x 2 (One for Backup, One for USB Mouse)
Controls Front panel, USB mouse, IR remote control,
Keyboard, Network
Disk info Disk Type SATA x 2 (up to 3TB)
Other info Voltage DC12V/3.3A
Optimal
Temperature
14°F to 131°F /-10°C to 55°C
10% to 90% Humidity
Power
Consumption
20W (without Hard Drive)
A.2 SPECIFICATIONS
Parameter QC814 QC824
Control Mode USB mouse, Network
Compression Compression
Format
H.264 and MPEG-4 dual codec
Video Video In
4 cameras max
4 channel input directly through POE block
Remote cameras may be accessed through network
Video Out
VGA x 1, HDMI x1
VGA Resolution 1920×1080, 1280×1024, 1280×720, 1024×768
Record Resolution 1080P(1920×1080) / 720P(1280×720) / D1
(704×576/704×480)
Record Frame Rate D1:
30fps/camera
720p:
30fps/camera
1080p:
15fps/camera
D1:
30fps/camera
720p:
30fps/camera
1080p:
30fps/camera
Record Bit Rate Up to 32Mbps
Supported IP
Cameras
Dahua, Arecont Vision, AXIS, Canon, Dynacolor,
Panasonic, Samsung, Sanyo, Sony, Onvif
Audio Audio Input 1 channel, RCA(200-2800mV, 30KΩ)
Audio Output 1 channel, RCA(200-3000mV, 5KΩ)
Alarm Alarm Input 0
Alarm Output 0
Storage Record Mode Manual/Schedule/Motion Detection/Camera Loss/
Camera Block
Multi-Function Simultaneously Record, View Live or Recorded
Video, Playback, Back-up files, Monitor Remotely
Interface Network Interface RJ45 (LAN, Internet)
Communication
Interface
RS485, RS232
USB 2.0 x 2 (One for Backup, One for USB Mouse)
Controls Front panel, USB mouse, IR remote control,
Keyboard, Network
Disk info Disk Type SATA x 1 (up to 3TB)
Other info Voltage DC12V/2A 48V/1A (POE)
Optimal
Temperature
14°F to 131°F /-10°C to 55°C
10% to 90% Humidity
Power
Consumption
20W (without Hard Drive)
