15
Heritage Range – H
600HL-1 Top / Back ducted
700HL-1 Top / Back ducted
900HL-1 Top / Back ducted
• Duct outlet dimension
top ducted 240 x 106mm
back duct 235 x 110mm
• Standard single motor ducting will fit
It is recommended that the hood be
positioned 700 to 800 above the cooktop.
QASAIR suggests 750 and the DLE flues
supplied are either 600/900/1200 or 1500
long. Please ensure you have the correct
flue before installing the hood.
Heritage Range – H
1200HL-2 Top / Back ducted
1500HL-2 Top / Back ducted
• Duct outlet dimension
top ducted 370 x 150mm
back duct 235 x 110mm
• Standard 2 motor ducting will fit
It is recommended that the hood be
positioned 700 to 800 above the cooktop.
QASAIR suggests 750 and the DLE flues
supplied are either 600/900/1200 or 1500
long. Please ensure you have the correct
flue before installing the hood.
