22
Shroud
The dimensions are shown on the diagram.
It is necessary to measure the height to the
ceiling on each side of the motor box so we get
the exact measurement to make the shroud.
We will leave a 2mm gap to allow for any
variation in the ceiling or hood installation.
Imperial Range – FASANO
FAS 900L-2 Top Ducted
FAS 1200L-2 Top Ducted
• Duct outlet dimension 250 square
• Standard twin motor ducting will fit
