QASAIR Installation Instructions
47
306. VB-3/45 Vertical Bend 45º
309. TR-3 Transition to 350ø
308. TMT-400x200/350 Transition from DL-3
to 350ø
307. TT-3 Twisted Transition
304. HB-3/45 Horizontal Bend 45º
305. VB-3 Vertical Bend 90º
301. 3MT-DL-3 Three Motor Transition
302. DL-3 Duct Length 1200mm
303. HB-3 Horizontal Bend 90º
‹‹ Triple Motor
312. DR-350/45 Bend 45º 350ø
311. DR-350 CB Duct Length 350ø Colourbond
310. DR-350 Duct Length 350ø
