2
SECTION PAGE
PRODUCT SPECIFICATIONS..................................................................................................................... 2
CALIFORNIA PROPOSITION 65................................................................................................................. 2
SAFETY GUIDELINES - DEFINITIONS ......................................................................................................
3
POWER TOOL SAFETY ............................................................................................................................. 4
TILE SAW SAFETY ..................................................................................................................................... 5
ELECTRICAL REQUIREMENTS AND SAFETY..........................................................................................
7
TOOLS NEEDED FOR ASSEMBLY............................................................................................................. 8
CARTON CONTENTS.................................................................................................................................. 8
KNOW YOUR TILE SAW............................................................................................................................. 10
ASSEMBLY AND ADJUSTMENTS.............................................................................................................. 13
OPERATION................................................................................................................................................ 19
MAINTENANCE........................................................................................................................................... 23
TROUBLESHOOTING................................................................................................................................. 24
PARTS LIST................................................................................................................................................. 25
MOTOR
Type ................................. Universal
Amps ............................... 15
Voltage ............................ 120
Hz ................................... 60
RPM (no load) ................. 4500
Overload Protection ........ NO
TABLE
Table Size ........................
17-5/16 in. x 14-13/16 in.
(440 mm x 375 mm)
Table Extension ............... Yes, right side of main table
SAW
Blade Size .................................. 10 in. (254 mm)
Arbor Size ................................... 5/8 in. (16 mm)
Blade Type .................................. Continuous rim diamond
Material Usage ............................ Porcelain, ceramics,
marble, stone
CUTTING CAPACITIES:
Bevel Range ............................... 0° - 45° right
Maximum Depth of Cut at 90° ..... 3-3/4 in. (95.2 mm)
Maximum Depth of Cut at 45° ..... 2-3/8 in. (61 mm)
Maximum Rip Cut ........................ 24 in. (609.6 mm)
Maximum Diagonal Cut ............... 18 in. (455 mm)
WARNING
!
•
•
•
WARNING
!
WARNING
!
