Qlima D620 User Manual

37
8
INDICATION LIGHT BAR
(1) When the machine is running, the blue light is on.
(2) When the water tank is full, the orange light is on and tank “Full” indication
light on
9
NIGHT MODE
Pressing the light button when the machine is working makes the buzzer bleep for
one time. Digital display, LED light and blue decoration light are off but the power
light is on. (Note: the child lock light is on if the machine is at child lock mode.) When
pressing the light button again the buzzer bleeps one time. Digital display works
normally, corresponding mode or function lights show normally.
WATER FULL
When tank is full, device will automatically shut off and buzzer will alarm 10 times.
The indication light of "power" and "tank full" will illuminate.
The dehumidifying process will only restart once the condensate tank has been
emptied and re-installed. Once re-installed correctly the LED will turn off. DO NOT
attempt to modify or remove the float mechanism; this could result in the tank
overflowing.
AUTO RESTART
1
If the unit is turned off unit and is in stand-by, the device will recall the last
setting when turned on again.
2
In the event of a power failure, the machine will restart automatically at the
settings selected prior to the power interruption.
3
If user sets the “child lock” and “timer” functions, the device will shut off when
time is up, but the child lock function will be turned off when the unit restarts.
AUTOMATIC DEFROSTING
When the machine is working in low temperatures the evaporator may frost. In
order to protect cooling system, this device is provided with an automatic
defrosting function.
COMPRESSOR PROTECTION FUNCTION
This device is equipped with a compressor protection function so the fan will run
for 3 minutes before the compressor kicks in.
REFRIGERANT LEAKAGE DETECTION FUNCTION
The refrigerant leakage function will shut off the device automatically if any leak is
detected. The digital display will flash and the buttons will be unresponsive until
the unit has been restarted.
CONTINUOUS DRAINAGE
Drainage hose 15mm is included. Insert drainage hose to drain outlet and extend
the hose to a suitable drainage facility.
4
37

Qlima D620 Specifications

General

Power	340 W
Best uses	Bedroom
Placement	Floor
Air filter	Yes
Noise level	34 dB
Product color	White
Housing material	Plastic
Number of speeds	3
Water tank capacity	4 L
Dehumidifying capacity (max)	20 l/24h
Suitable for room volume up to	130 m³
International Protection (IP) code	IPX4
Operating temperature (T-T)	0 - 35 °C
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Package depth	307 mm
Package width	398 mm
Package height	631 mm
Package weight	15000 g

Weight and Dimensions

Depth	253 mm
Width	346 mm
Height	590 mm
Weight	14000 g
